This is the Futaba 4PLS 2.4GHz T-FHSS Radio System
with the R304SB 4-Channel Telemetry Receiver.
Transmitter and Receiver only, servos not included.
FEATURES: T-FHSS (telemetry), FHSS and S-FHSS transmission modes
Temperature, voltages and RPM can be monitored in real-time, and
logged for future reference (sensors not included, must be
purchased separately, see COMMENTS below)
40 model memory
10 character model naming and user name
Fail safe on all channels
Large 128x64 dot backlit LCD display with contrast adjustment
Gyro, dual ESC, four wheel steering and brake mixing
Anti-skid braking system
Throttle acceleration reduces time lage of clutch & brake operation
Throttle and steering speed adjustment
Racing timer records 100 lap times and total time
One programmable mix
User updatable software using the CIU-2 PC Interface (not included)
Data logging at user-settable intervals
Model data transfer, model copy and model clear
Steering wheel and trigger adjustments
One year limited warranty through Futaba beginning at date of
INCLUDES: Futaba 4PLS 2.4GHz T-FHSS Radio System, R304SB Receiver, On/Off
Switch, Mini Screwdriver, and Instruction Manual
REQUIRES: AA Batteries: Four for transmitter
(You may also use a 2C 6.6V LiFe battery such as HCAM6521)
Servos of modeler's choice
SPECS: T-FHSS/S-FHSS/FHSS Transmitter;
Transmitting Frequency: 2.4GHz
Power Requirement: Four AA
Current Drain: 150mA or less
Transmission Antenna: 1/2 di-pole
Power Requirement: 4.8 - 7.4V battery
Receiving Frequency: 2.4GHz
System: T-FHSS (auto detection)
Dimensions: 1.38 x 0.91 x 0.33" (35.1 x 23.2 x 8.5mm)
Weight: 0.23oz (6.6g)
COMMENTS: The following sensors will work with this system;
Temperature Sensor, FUTM0854
RPM Sensor, FUTM0852
Voltage Sensor, FUTM0855
If wanting a LiFe battery for the transmitter, the Hobbico LiFe 6.6V
1900mAh 2 Cell Battery Pack (HCAM6521) is an ideal choice.
This is the Futaba 3PV 3-Channel Radio System
with the 3-Channel R203GF Receiver.
FEATURES: FHSS/T-FHSS, S-FHSS protocols
Large, easy to read programming screen
Four wheel steering and brake mixing
Model data copy
Anti-lock brake system (ABS) function
R203GF 3-channel receiver is ideal for brushless ESCs and digital
Throttle fail safe
Steering and throttle trim
Channel 4 trim
Steering dual rate adjustment
Steering and throttle end point adjustment
Channel 3 and 4 end point adjustment, and servo reversing
Steering and throttle exponential
Auto power off after ten minutes
One year limited warranty through Hobby Services beginning at date of
INCLUDES: Futaba 3PV 3-Channel Transmitter, 3-Channel R203GF Receiver,
REQUIRES: AA Batteries: Four for transmitter (may also be powered by the
Futaba HT5F1800B 6V NiMH pack FUTM1482, or the Hobbico LiFe 6.6V
1900mAh pack, HCAM6521
Transmitting Frequency: 2.4GHz band
Power Requirement: Four AA cells
Current Drain: 100mA or less
Transmission Antenna: Dipole (built in)
Communication Method: Two way T-FHSS,one way S-FHSS, FHSS
R203GF Receiver, FUTL7603;
Dimensions: 1.54 x 0.91 x 0.33" (39 x 26 x 10mm)
Weight: 0.28oz (8g)
Operating Voltage: 4.8 - 7.4V (shared with servo)
Battery Fail Safe Voltage: 3.8V*
Current Drain: 30mA at no signal
*Battery fail safe voltage is set for 4-cell NiCd/NiMH battery.
Battery F/S does not work properly when other type of battery is used
Antenna Length: 7.5" (190.5mm)
A built in internal stinger gives a nice throaty tone, while only putting out less than 92 dB in most applications. This also eliminates the need for a bulky external muffler.
Made from polished stainless steel, so there is no chance of water leaking into your exhaust, killing performance.
Pipe measures about 17-1/4 inches long and has a stinger ID of .440 inch.
Fits 7/8 inch headers only.
For stock engines,the tuned length for this pipe is exactly 13.5 inches from the face of the exhaust flange (measured around the header, on the centerline).
For modified engines, start at 13.5 inches and shorten from there. The pipe is very sensitive to length.
Shorten 1/8 inch at a time and test.
Note: We recommend that you DO NOT do any of the following:
Grind away any internal welds
Use an add on muffler
Put side pressure on the pipe to mount it
Doing any of the above may cause your pipe to crack or break.
Use the pipe as it ships. You will enjoy it for a long time.
Mount the pipe as loose as possible. Hard or stiff mounts break pipes.
Includes super tuned pipe and stainless steel clamp.
This is the Futaba 3-Channel 3PMX Computer Radio with the
2.4GHz FASST System.
Transmitter and R603FF receiver only, servos not included.
The 3PMX is also capable of using the R603FS receiver
to give modelers special Dual Antenna Diversity (DAD).
**The 3PMX adds three new features; Four Wheel Steering Mixing,**
**Digital Trim Step and Adjuster for Crawlers, Monster Trucks**
**and any four wheel drive vehicle. These features allow drivers**
**to apply mixing between steering, throttle and channel 3.**
FEATURES: FASST (Futaba Advanced Spread Spectrum Technology) sends twice as
much information to the receiver at eight times the resolution of
standard systems for unsurpassed control and smooth servo travel
2.4GHz circuitry is wired directly into transmitter eliminating
separate plug-in modules
"Auto Detect" instantly determines whether HRS or PPM mode is active
in the receiver (R603FS only)
Special ID code prevents signal interruption by rejecting unwanted
Brake mixing for large cars
Anti-skid braking system (ABS)
Throttle Acceleration (ACC) minimizes time lag before clutch and
brakes are connected in gasoline engine cars
Steering speed adjusts steering servo operating speed
Function select lever function
In addition to great performance in R/C car and truck applications,
this system is also ideally suited to the rigors of boat racing
10 Model Memory
One year limited warranty through manufacturer
INCLUDES: 2.4GHz FASST Futaba 3-Channel 3PMX transmitter
2.4GHz FASST Futaba R603FF 3-Channel Receiver (FUTL7631)
ON/OFF switch harness
REQUIRES: AA Batteries: Eight for transmitter
Servos of modeler's choice
Current Drain: 250mA or less
Transmitting Antenna: 2.4GHz
Reception Antenna: External
Power Requirement: 6V NiCd battery
Size: 1.5 x 1 x 0.55" (39 x 26 x 14mm)
Weight 0.45oz (12.8g)
